Custom IP65/IP66-rated Power Distribution Panel and Electrical Enclosure with 220V/380V Nominal Voltage

Custom IP65/IP66-rated Power Distribution Panel and Electrical Enclosure with 220V/380V Nominal Voltage

ब्रांड नाम:	WeSeW
एमओक्यू:	1 टुकड़ा
कीमत:	US$200~US$1000/pc
भुगतान की शर्तें:	टी/टी, वेस्टर्न यूनियन
आपूर्ति करने की क्षमता:	कांच की बोतल, प्लास्टिक की बोतल

विस्तार से जानकारी

उत्पाद का वर्णन

विस्तार से जानकारी

उत्पत्ति के प्लेस:

चीन

प्रमाणन:

CE,UL

आवेदन:

पावर चरण संख्या:

टी/टी

नाममात्र वोल्टेज:

220V/380V

पैकेजिंग विवरण:

लकड़ी का केस

आपूर्ति की क्षमता:

कांच की बोतल, प्लास्टिक की बोतल

प्रमुखता देना:

IP65/IP66-rated Power Distribution Panel

Customizable Electrical Enclosure

220V/380V Metal Cabinet

उत्पाद का वर्णन

Custom IP65/IP66-Rated Control and Power Distribution Metal Enclosures

Complete sets of power distribution cabinets, sheet metal parts riveting assembly, and sheet metal parts bending. We undertake large and high-capacity production line assembly parts production.

Product Name	Sheet Metal Processing
Style	Sheet Metal Customization
Brand	Nam Billion
Colour	Customizable, White, Blue-White, Matte Beige

Equipment Classification and Suitable Scenarios

Stage distribution boxes are primarily categorized into fixed and mobile types. Fixed distribution boxes are permanently installed on walls or bases, meeting seismic and heat dissipation requirements, and are suitable for permanent performance venues such as theaters and concert halls. Mobile distribution boxes, exemplified by flight case distribution cabinets, feature sliding wheels and double-layer shockproof structures for quick installation and removal. They are ideal for temporary scenarios like music festivals and touring performances. Some models offer customizable output specifications based on requirements.

Core Performance and Safety Configuration

Load Capacity and Protection Standards

Select distribution boxes with rated currents exceeding total equipment power by 20%
Single-box load must not exceed 80% of rated capacity
Protection ratings must match usage environments—outdoor performances require IP54 or higher
Equipped with residual current devices (RCDs) with action currents ≤30mA
Grounding resistance ≤4Ω

Component and Wiring Standards

Use switchgear components from brands like Chint or Delixi
Main circuits employ copper-core conductors
Separate distribution cables from low-voltage lines to prevent signal interference and safety hazards
Temporary overhead lines must be ≥2.5m above ground (≥5m over vehicular traffic lanes)
Buried lines require ≥0.7m depth

Management and Operation Requirements

Qualifications and Approval

Distribution boxes must be nationally standardized products
On-site electricians must hold valid operation certificates
Implement tiered approval based on power load levels
Temporary power permits must specify usage periods
Extensions require submission of assessment reports 15 working days in advance

Inspection and Emergency

Inspection frequency shall be determined by load level
Class I loads (>1000kVA) require daily inspections
Emergency lighting and evacuation signage shall be provided
Emergency lighting maintains continuous operation for no less than 30 minutes

Product Gallery
