Customized Stainless Steel Spiral Sand Washer with 40-280 tons/hour Capacity for Efficient Gravel Washing

Customized Stainless Steel Spiral Sand Washer with 40-280 tons/hour Capacity for Efficient Gravel Washing

ब्रांड नाम:	WeSeW
मॉडल संख्या:	काई001
एमओक्यू:	1 टुकड़ा
कीमत:	US$20,000~US$80,000 per pc
भुगतान की शर्तें:	टी/टी, वेस्टर्न यूनियन
आपूर्ति करने की क्षमता:	प्रति माह 10000pcs

विस्तार से जानकारी

उत्पाद का वर्णन

विस्तार से जानकारी

उत्पत्ति के प्लेस:

चीन

प्रमाणन:

CE,UL

सामग्री:

स्टेनलेस स्टील/कस्टम

सामग्री सुविधा:

गर्मी प्रतिरोधी, आग प्रतिरोधी

आवेदन:

रासायनिक उद्योग, अनाज परिवहन, खनन परिवहन, बिजली संयंत्र

कोर घटक:

मोटर

आयाम (l*w*h):

स्वनिर्धारित

विनिर्देश:

स्वनिर्धारित

संरचना:

कन्वेयर

पैकेजिंग विवरण:

लकड़ी का केस

आपूर्ति की क्षमता:

प्रति माह 10000pcs

प्रमुखता देना:

Customized Spiral Sand Washer

Stainless Steel Screw Sand Washing Machine

40-280 tons/hour Sand Screw Washer

उत्पाद का वर्णन

Customized Single Spiral Aggregate Sand Gold Washing Machine

Our industrial-grade Spiral Sand Washing Machine efficiently cleans and separates dirt, dust, and impurities from sand, gravel, or crushed stone. Utilizing a rotating screw mechanism with water flow, it delivers high-quality washed materials for construction, mining, and aggregate applications.

Key Features

High cleaning efficiency: Removes dirt, clay and organic impurities effectively
Low water consumption: Environmentally friendly operation
Robust construction: Made of wear-resistant steel for durability
Energy efficient: AC motor with ISO9001 & CE certifications
Comprehensive support: 1-year warranty with lifetime spare parts supply

Technical Specifications

Product Name	Industrial Spiral Screw Classifier Sand Washing Machine
Motor Type	AC Motor
Capacity	6-400t/h
Core Components	Bearing, Gearbox, Motor
Weight	500 KG
Applications	Motorway construction, hydropower projects, building material washing, classification

Detailed Technical Parameters

Model	Spirals Number	Screw Diameter (mm)	Sink Length (mm)	Capacity (t/h)	Motor Power (kw)
XL920-7.5	1	920	3600	40-60	4P-11
2XL920-7.5	2	920	7500	90-120	4P-11X2
XL1120-7.5	1	1120	5000	40-120	4P-18.5
2XL1120-7.5	2	1120	10000	80-240	4P-18.5X2
XL1500-9	1	1500	9800	100-170	4P-22
2XL1500-9	2	1500	18000	200-280	4P-22X2

Working Principle

The Spiral Sand Washer operates through a synergistic process of agitation, settling and material transportation. As the sand-cement slurry enters the inclined trough, the rotating spiral blades agitate the mixture while gravity settles heavier sand particles. Lighter impurities remain in suspension and are washed away by water flow. The spiral simultaneously conveys the cleaned sand up the slope while discharging excess water through tank holes.

Environmental Protection Measures
